GUARDENA SECURITY FENCING offers a comprehensive system of gates and wickets designed to integrate seamlessly with the panel fencing, providing a complete and adaptable solution for your security needs. These versatile components are engineered to work together flawlessly, ensuring maximum functionality and a cohesive aesthetic.

COMPREHENSIVE SECURITY SOLUTION

The GUARDENA Security Fencing system offers a complete solution with various panels, gates, and wickets for a cohesive and secure perimeter. Choose from different styles and sizes, including pedestrian, double-leaf, and sliding gates, all matching the panels.

ADAPTABLE TO DIVERSE NEEDS

GUARDENA Security Fencing is a highly adaptable system with a range of panels, gates, and wickets to suit diverse security needs, from residential to high-security applications. It offers various styles, sizes, and access control options for tailored protection.

DURABLE AND LONG-LASTING

GUARDENA Security Fencing is built to last, using pre-galvanised steel for exceptional corrosion resistance. Both panels and gates are further protected with a galvanised finish or a galvanised finish with polyester paint coating for long-lasting performance and minimal maintenance.

V-MESH SECURITY FENCES

2D or 3D filling possible

V-MESH SECURITY FENCES

Technical specification of panels:
– Welded mesh panel made of horizontal and vertical galvanized wires with a diameter of: Eco Ø 4 mm, Standard Ø 5 mm, Heavy Strong Ø 6 mm
– Mesh size: 50 mm x 200 mm, in the area of the stiffening embossing: 50 mm x 50 mm
– Panel width: 2500 mm (50 vertical wires)
– Panel height: 1030 mm, 1230 mm, 1530 mm, 1730 mm, 2030 mm, 2230 mm, 2430 mm
– Panel with single-sided 30 mm high extended wires
– Panels are powder coated using PPA571 Plascoat® FLUIDIZED BED technology
– Available in the following RAL colours: 7016, 9005, 6005
– Fluidized bed technology guarantees 25 years of corrosion protection (full description in the “about us” tab)

Technical specification of fence posts:
– Cold-bent galvanized steel profile with dimensions of 40 mm x 60 mm x 1.3 mm
– Post height: 1700 mm, 2000 mm, 2200 mm, 2400 mm, 2600 mm, 3000 mm, 3200 mm, 3400 mm
– Powder coated with polyester paint

FENCE PLINTH CLIP (BRACKET)

Technical specification of fence fasteners (post + panel):
– Intermediate fastening
– 90° corner fastening
– Starting-ending fastening
– Galvanized M8 screws and nuts
– Plastic connecting clips (screw-panel)
– Available in the following RAL colours: 7016, 9005, 6005

Technical specification of prefabricated foundation:
– Height: 200 mm, width: 40 mm, length: 2520 mm
– Slab reinforced with 6 mm diameter wires, made of architectural concrete
– Foundation fastened to the post with plastic U-shaped brackets in
the colour of the post

TWIN MESH SECURITY FENCES

2D or 3D filling possible

TWIN MESH SECURITY FENCES

Technical specification of panels:
– Welded mesh panel made of galvanized wires with a diameter of: Vertical (single) Ø 5 mm, Horizontal (double) Ø 6 mm
– Mesh size: 50 mm x 200 mm
– Panel width: 2500 mm (50 vertical wires)
– Panel height: 1030 mm, 1230 mm, 1430 mm, 1630 mm, 1830 mm, 2030 mm, 2230 mm, 2430 mm
– Panel with single-sided 30 mm high extended wires
– Panels are powder coated using PPA571 Plascoat® FLUIDIZED BED technology
– Available in the following RAL colours: 7016, 9005, 6005
– Fluidized bed technology guarantees 25 years of corrosion protection (full description in the “about us” tab)

Technical specification of fence posts:
– Cold-bent galvanized steel profile with dimensions of 40 mm x 60 mm x 1.3 mm
– Post height: 1700 mm, 2000 mm, 2200 mm, 2400 mm, 2600 mm, 3000 mm, 3200 mm
– Powder coated with polyester paint

FENCE PLINTH CLIP (BRACKET)

Technical specification of fence fasteners (post + panel):
– Intermediate fastening
– 90° corner fastening
– Starting-ending fastening
– Galvanized M8 screws and nuts
– Plastic connecting clips (screw-panel)
– Available in the following RAL colours: 7016, 9005, 6005

Technical specification of prefabricated foundation:
– Height: 200 mm, width: 40 mm, length: 2520 mm
– Slab reinforced with 6 mm diameter wires, made of architectural concrete
– Foundation fastened to the post with plastic U-shaped brackets in the colour of the post

GUARDENA SYSTEM COLOURS

GUARDENA fences are built to last, combining the protective properties of zinc coating with the aesthetic enhancement of a varnish coating. This dual protection ensures your fence remains beautiful and resilient in all weather conditions. Choose from either hot-dip galvanised or galvanised with a polyester paint coating for long-lasting performance and visual appeal.

DARK GREEN | RAL6005

ANTHRACITE GREY | RAL7016

BLACK | RAL9005
